Features
- PETROL-POWERED – 192cc engine with up to 8 hours of runtime (at 25% load)
- SAFE CONNECTION – True Sine Wave technology allows you to confidently connect your electronics
- WATTAGE – OHV Champion engine produces 3500 maximum watts and 3200 running watts
- MULTIPLE OUTLETS – Including two 240V 13A outlets and a 12V DC outlet.
- PEACE + QUIET – Only 58 dBA for quiet running.
- EASY TRANSPORT – Built-in handle and wheel kit for ease.
- SMART ECONOMY – Designed with a low oil shut-off sensor and economy mode to save fuel.
- LINK + BOOST – Connect this inverter with another Champion 3500-watt inverter for 30 amps of power with the option ParaLINK Parallel Kit.
Pay in 3 interest-free payments
Split your purchase into 3 payments, over 3 months with no sign-up fees or late fees.
- Choose Paypal at checkout to pay later with Pay in 3.
- Complete your purchase with the first payment today.
- Remaining payments are taking automtically.
Available for purchases of £30 to £2,000. Pay in 3 eligibility is subject to status and approval. 18+ UK residents only. Pay in 3 is a form of credit, may not be suitable for everyone. Use may affect your credit score or make credit less accessible or more expensive for you. Consider if affordable for you. Terms and conditions apply. PayPal Pay in 3 is a trading name of PayPal (Europe) S.à r.l. et Cie, S.C.A. 22-24 Boulevard Royal L-2449, Luxembourg.
Starting Watts | 3750 |
---|---|
Max Watts | 3500 |
Rated Watts | 3200 |
AC Load | 2 x 240v 13amp |
Socket Rating | 13 |
DC Output | 12 / 8.3 |
Phase | Single |
Power Factor | 1 |
RPM | Automatic (Based on load) |
Engine | 192cc |
Fuel Capacity | 6 Litres |
Oil | 10W-30 |
Oil Capacity | 0.6 Litres |
Start Type | Recoil |
Low Oil Shutoff | Automatic |
Choke Type | Manual |
Noise Level @ 7m | 58 dBA |
Dimensions L*W*H (Fully Assembled) |
61 x 47 x 50 cm |
Weight | 36.9 kg (81.4 lbs) |
Operation at 25% (Eco Mode) | 8 hours |
Overload Protection | Yes |
Intelligauge | Yes |
Parallel Connectivity | Yes |
Wheels | Never Flat |
Emissions | EC |
Certification | CE EU Stage V E10 Petrol Compliant |
Warranty | 3 Year Limited Warranty |
What's in the box:
- Champion 3500 Watt Inverter Petrol Generator
- Smart Charger
- 12V DC USB Adapter
- 12V DC Battery Charging Cable
- Oil Funnel
- Wrench
- Operating manual
Wattage Reference Guide*
HOME | RUNNING | STARTING |
---|---|---|
Microwave | 1000 | 0 |
Coffee Maker | 1500 | 0 |
Lamp | 100 | 0 |
LED/LCD TV | 150 | 0 |
Laptop | 800 | 0 |
Modem/Router | 20 | 0 |
RECREATION | RUNNING | STARTING |
---|---|---|
Slow Cooker | 200 | 200 |
Blender | 300 | 650 |
Fan | 200 | 0 |
LED/LCD TV | 150 | 0 |
Radio | 100 | 0 |
Game Consol | 1500 | 0 |
ON THE JOB | RUNNING | STARTING |
---|---|---|
Drill | 600 | 900 |
Air Compressor | 1600 | 4500 |
Circular Saw | 1200 | 2000 |
Hand Sander | 600 | 1200 |
Work Light | 1000 | 0 |
Paint Sprayer | 600 | 600 |
OUTDOORS | RUNNING | STARTING |
---|---|---|
Lawn Mower | 1200 | 2400 |
String Trimmer | 350 | 875 |
Hedge Trimmer | 450 | 1200 |
Edger | 950 | 2400 |
Chainsaw | 1200 | 2400 |
Pressure Washer | 1200 | 2400 |
EMERGENCY | RUNNING | STARTING |
---|---|---|
Refridgerator | 700 | 2200 |
Sump Pump 1/2 hp | 800 | 1300 |
Well Pump 1/2 hp | 1000 | 2100 |
Furnace 1/4 hp | 600 | 1000 |
Water Heater | 4000 | 0 |
Window AC | 1800 | 2800 |
How to calculate:
RUNNING WATTS NEEDED
Total running watts of ALL items to be powered by the generator at the SAME TIME.
STARTING WATTS NEEDED
Add highest SINGLE starting Watt to the total RUNNING WATTS needed above.
*This chart is for reference only. Check your device for ACTUAL wattage requirements.
Reviews and Q&A
-
has it got electrical remote start together with recoil pull starting
Start Type: Recoil
-
Hi Does this model come with a guarantee? Thanks Glenn
Champion equipment (selected Champion products) warrants to the original purchaser up to 3 Years for domestic usage that the mechanical and electrical components will be free of defects in material and workmanship for a period of One (1) year [Parts and Labour] Year Two (2) and Year Three (3) [Parts Only] from the original date of purchase or a 1000 hours which ever comes first.
-
Can this be connected to a house supply through a Manual Transfer Switch (MTS) as a back up generator?
Yes, it can be installed into a manual transfer switch, but this is something that we do not facilitate
This will be able to provide backup power.
